R32 GTR front coilover bottom mount - flared side in or out

[MrStabby]

Replacing these and want to check the orientation for the bottom mount on the coilover as its not symmetrical. Is flared/longer section supposed to facing inside or out?

The ones i'm removing have the flared side facing out where the nut is, but assuming the flared bit is there to ease fitment it looks like it should face the other way.

Thanks.

[Duncan]

Got a pic?

If you mean the washer, I put the larger one in as it has a larger face to hold against, and the smaller one out as it only has a nut on it

[Duncan]

Glad to hear you still have the 32 BTW

[MrStabby]

Found this https://www.skylineowners.com/threads/coilover-fitting-help.143959/

Which says "there the fronts, long end goes in 1st, so nut and washer fits on short side."

According to that the long, flared end goes towards the inside facing the suspension and the short side + washer goes on the outside. I installed it that way and it looks better that way as the coilover is spaced further away. There's no witness marks on the the old suspension or coilover, so it probably doesnt matter much.

I'll see if i can find a photo



[MrStabby]

This shows the bottom mount

[Duncan]

Ahh I see. I don't know, not all shocks are setup like that.

Other than clearance it doesn't matter much because it is double wishbone, so ignore how it was and just out them in whichever way fits best

[r32-25t]

Flared side goes in

[MrStabby]

12 hours ago, r32-25t said:

Flared side goes in

Agreed - looks better that way

[GTSBoy]

It is definitely to space it out and away for clearance during compression, and possibly for spring clearance to upper arm. That latter would only be true for springs that are same-ish diameter to stockers, and so that probably doesn't apply to Teins or most other coilovers.
